MIDIS AV Tshaj IP Server

Kev ua tau zoo

Muaj kev nyab xeeb thiab ruaj khov

Txais yuav cov chips tsim hauv tsev, tsim los ntawm kev kos Linux system, tsis muaj kab mob

Kho vajtse Configuration

CPU core: HiSilicon Hi 3536, quad-core A17 processor, Main zaus: 1.4 GHz;

RAM: 2 GB

Internal cia: 256 GB

Data Interface

USB2.0 Hom- A Ntaus Chaw nres nkoj *1;

USB3.0 Hom- A Ntaus Chaw nres nkoj *1;

Network Interface

3 RJ45 Gigabit Ethernet chaw nres nkoj, txhawb PoE fais fab mov;

Ntaus Loj

Chassis loj: 436.8 * 280 * 46.5mm;

Dimensions nrog dai pob ntseg: 482 * 300 * 46.5;

Input voltage

DC12V, Tsawg dua lossis sib npaug rau 1A;

Kev tiv thaiv tam sim no

3.5mA ua

Cov cuab yeej siv hluav taws xob

Tsawg dua lossis sib npaug li 7 W;

Khoom siv suab nrov

Fanless thiab ntsiag to tsim;

Ua haujlwm kub

- 10 degree ~ 45 degree ua haujlwm kub;

Qhov hnyav

Net nyhav 3.16 Kg, tag nrho hnyav 4.60 Kg;

Qhov taw qhia Teeb

Lub Zog Hluav Taws Xob Teeb Pom Teeb Meem: Lub Teeb Yuav Nyob Rau Thaum Tus Neeg Rau Cov Neeg Mob Lub Sij Hawm Ib Zaug;

Khiav qhov taw qhia lub teeb: Lub teeb yuav flash thaum lub server pib thiab khiav ib txwm;

Kev sib txuas qhov taw qhia: tshwj tseg, flashes randomly thaum ua haujlwm;

Kev teeb tsa

Kev them nyiaj yug 1U ywj siab txee installation;

Cov yam ntxwv ntawm qhov system

Txhawb cov cuab yeej tswj, tswj cov codecs, audio processors, network audio servers, hyper-converged nodes, media servers, central tswj hosts, kaw thiab tshaj tawm, splicing tswj matrices, saib xyuas IPCs thiab thib peb-tog docking network li;

Txhawb kev tswj hwm ntawm cov teeb liab xov xwm loj heev thiab ultra-high-resolution video signals;

Txhawb ntau tus neeg siv kev tswj hwm thiab tus neeg siv txoj cai teeb tsa;

Txhawb ntau lub kaw lus cascading muaj nuj nqi kom paub txog kev sib txuas ntawm cov ntaub ntawv audio thiab video ntawm cov tshuab;

Txhawb ntau pawg tswj kev tshuaj ntsuam, paub txog LCD/LED npo splicing, thiab tswj cov teeb liab projection zaub;

Txhawb kev tshuaj ntsuam banner teeb tsa muaj nuj nqi;

Txhawb nqa streaming media forwarding muaj nuj nqi, RTSP streaming media forwarding yog tso tawm kom pom ntawm qhov screen;

Txhawb ntau tus neeg rau zaub mov kub thaub qab muaj nuj nqi txhawm rau txhim kho kev ntseeg tau;

Txhawb lub hauv paus tswj kev ua haujlwm, paub txog kev tswj cov cuab yeej ib puag ncig, thiab txhawb nqa ob txoj hauv kev tswj cov khoom siv ib puag ncig (xws li lub koob yees duab taug qab);

Txhawb nqa peb-tog network platform docking, xws li saib xyuas platform (GB/T28181 raws tu qauv), video conferencing MCU, thiab customized docking ntawm lwm tus neeg sab nrauv ntaus ntawv API thiab SDK raws tu qauv;

Txhawb qhib neeg rau zaub mov platform API interface raws tu qauv rau cov neeg thib peb docking;

Codec node tswj thiab tswj

Txhawb cov cuab yeej hauv online raws li txoj cai tswj;

Txhawb online batch upgrade ntawm ntaus ntawv software version;

Txhawb kev hloov kho qhov screen thiab encoding cov video tso saib tom qab duab;

Txhawb kev txiav txim siab ntawm qhov splicing, teeb liab zaub, thiab kev tshuaj ntsuam layout switching;

Txhawb nqa codec node ntim tswj thiab central tswj interface tswj;

Audio Processor Control

Txhawb suab processor scene hu, tab sis tsis txhawb scene txuag;

Txhawb lub suab tswj thiab ntim tswj ntawm lub suab processor input thiab tso zis raws, txhawb lub sij hawm tawm tswv yim ntawm lub suab dynamic, thiab txhawb kev sib xyaw;

Hyper-converged node tswj thiab tswj

Txhawb hyper-converged node ntaus ntawv tswj; txhawb hyper-converged node kaw thiab tshaj tawm xov xwm tswj, taw tes-rau-taw tes tswj, qhib qhov rais tswj, RTSP nkag mus rau qhov chaw hloov, video input interface hom hloov, input audio channel tswj, tso zis suab channel tswj, built-in central tswj (serial chaw nres nkoj, infrared transmitter chaw nres nkoj, lub sij hawm fais fab mov), thiab ib qho tseem ceeb pab muaj nuj nqi;

Mos Ntsuam Xyuas Projection

Txhawb Windows lossis MAC khoos phis tawj los muab cov kev pabcuam wireless /wired network screen, thiab txhawb synchronous audio thiab video kis;

Saib xyuas IPC tswj

Txhawb IPC network lub koob yees duab lub koob yees duab tswj, rub saib xyuas cov dej ntws los tso rau ntawm qhov screen, txhawb IPC PTZ tswj;

Saib xyuas lub platform tswj

Txhawb nqa lub teb chaws tus qauv GB / T28181 raws tu qauv los txuas rau kev soj ntsuam platform, tau txais cov npe ntawm cov xov xwm teeb liab ntawm kev soj ntsuam cov khoom siv platform, tswj cov zaub ntawm cov teeb liab tawm ntawm lub vijtsam, thiab txhawb PTZ tswj kev saib xyuas platform;

Lub rooj sib tham video MCU tswj

Txhawb Huawei, Polycom, thiab Dongwei video conferencing MCU docking, tau txais cov npe ntawm cov xov xwm teeb liab ntawm kev sib tham video MCU terminals tuaj koom lub rooj sib tham, thiab tswj cov zaub ntawm cov teeb liab tawm ntawm lub vijtsam;

Tswb linkage

kev nkag mus rau lub tswb lag luam los ntawm Morning Eagle, MetLife, New Hengzong, Hikvision, Dahua, thiab Putek, thiab paub txog kev tswj xyuas kev sib txuas ntse, xws li kev sib txuas rau kev tshuaj ntsuam, kev txuas mus rau kev kaw suab, lossis kev sib txuas rau kev hloov khoom siv thaum tau txais lub tswb;

UI Client

Txhawb kev khiav ntawm Kylin, Windows 7/10/11, Android, thiab iOS system platforms ;

Txhawb cov neeg siv los tsim tus kheej tswj interface; txhawb kev tsim ntawm ntau pawg ntawm kev tswj hwm interface;

Txhawb kev pom kev sib txuas los koom ua ke lub sijhawm teeb tsa suab thiab video, tswj lub suab, thiab tswj cov khoom siv ib puag ncig;

Txhawb kev tso saib ntawm ntau yam khoom xws li cov nyees khawm, cov npe, sijhawm, pob qhov rooj, faders, qib, ntoo directory, kho lub thawv, duab, thiab lwm yam.

Tswj raws tu qauv

Txhawb UDP, TCP, HTTP network raws tu qauv tswj;

Txhawb cov ntawv, hexadecimal, thiab infrared hom raws tu qauv tswj;

Txhawb ONVIF thiab GB T- 28181 raws tu qauv PTZ tswj ;

Logic Programming

Txhawb kev tswj kev sib xyaw ua ke daim ntawv thov, txhawb nqa cov npe ua tiav cov txheej xwm, thiab kev txiav txim siab thiab xaiv cov txheej xwm ua tiav;

Txhawb nqa bidirectional ua kom tiav kev tshwm sim kho;

Txhawb lub sijhawm ua kom tiav cov xwm txheej, cov xwm txheej ua tiav raws sijhawm, thiab cov xwm txheej ua haujlwm cyclic;

Media raws tu qauv

Txhawb kev tswj interface tshuab, sib xws nrog cov kev cai hauv qab no:

Txhawb AAC, G.711, G.722 audio format encoding thiab decoding;

Txhawb kev tswj hwm ntawm DANTE, CobraNet, thiab TAC suab raws tu qauv;

Txhawb H.264 thiab H.265 video hom encoding thiab decoding, txhawb RTP thiab RTSP xov xwm raws tu qauv;

Kev tu vaj tse

Kev them nyiaj yug system configuration ntshuam/export muaj nuj nqi;

Txhawb nqa phau ntawv kaw lus thaub qab, teem sijhawm thaub qab, thiab ib-nias teeb tsa kho dua tshiab;

Txhawb kev khaws cia thiab xa tawm cov ntaub ntawv kaw lus, suav nrog cov neeg siv cov ntawv teev npe, cov ntawv teev npe nkag, cov ntawv teev cov haujlwm, cov ntawv teev lus debug, thiab cov ntawv ceeb toom;

Txhawb kev saib xyuas thiab tshuaj xyuas cov xwm txheej hauv online ntawm node cov cuab yeej;

Txhawb batch upgrade ntawm codec node software version;
